OWON 3-CH Output with 2-CH 0-30V/6A and 0-6V/3A Programmable DC Power Supply

- Three independent controllable channels
- Output resolution : 1mV / 1mA
- Low ripples / low noise
- Up to 100 group timers
- Multi- working mode : individual, parallel, and series
- Over-voltage / Over-current protection
- Data-logging function: could record the output voltage, and current;
and display recorded data in chart
- Auto-cooling system
- 4 inch high resolution (480 × 320 pixels) LCD
- Multi- CI: USB, RS232, and LAN
- SCPI, and LabVIEW supported

Send Inquiry

Product Details

We are known as one of world's leading China manufacturers and suppliers. Welcome to buy the famous brands' OWON 3-ch output with 2-ch 0-30v/6a and 0-6v/3a programmable dc power supply, 378w, 30v power supply, 6a power supply with cheap price from us. We have many products in stock at your choice. Consult the quotation with us now.

1. Triple Output: 3 independent channel

function as 3 power supply unit;

via parallel / series connection, the power output range of 1 channel could be wider.

2. Creative Data Recording Function

to monitor the changing status of powering system, displaying recorded data in chart. E Low Ripples / Low Noise

3. Timing Output

Support 100 groups timing output settings, the power output curve could be adjusted via PC,

or device itself. And applicable to artificial simulated power output variation.

4. CV / CC Auto-switch

Along with load varies, the power output auto-switches between CV / CC.

Give an operation example, in the circumstance you set a voltage of 10V at a current of 1A,

when actual current not larger than 1A, the power supply unit works under CV status,

the power output alters with load accordingly; whereas when actual current larger than 1A,

the power supply unit will limit the current automatically, and switch into CC mode,

then the power output alters with load accordingly.

CV / CC auto-switch fulfills within power supply unit, no human intervention needed.

5. Low Ripples / Low Noise

OWON ODP features super- low ripples, and super- low noise,

which causes almost no influences to circuit test.

Video

ODP 3-channel Power Supply Introduction

Specifications

Model	ODP3033	ODP3063	ODP6033
Channel	3 (independent controllable channel)
Max Output Power	198W	378W	378W
Output Range	0 - 30V / 3A x 2-CH, 0 - 6V / 3A	0 - 30V / 6A x 2-CH, 0 - 6V / 3A	0 - 60V / 3A x 2-CH, 0 - 6V / 3A
Display
LCD Type	4 inch colored LCD
Display Resolution	480 x 320 pixels, 65536 colors
Mechanical Specifications
Dimension (W x H x D)	250 x 158 x 358 (mm)
Device Weight	9.80 kg	12.00 kg

The specifications based upon the instrument having run for at least 30 minutes continuously, under the specified operating environment

Model		ODP3033		ODP3063		ODP6033		all 3 models
Channel		CH1	CH2	CH1	CH2	CH1	CH2	CH3
Output Ratings （0℃-40℃）	Voltage	0 - 30V		0 - 30V		0 - 60V		0 - 6V
Output Ratings （0℃-40℃）	Current	0 - 3A		0 - 6A		0 - 3A		0 - 3A
Load Regulation	Voltage	≤0.01% + 3mV
Load Regulation	Current	≤0.01% + 3mA
Line Regulation	Voltage	≤0.01% + 3mV
Line Regulation	Current	≤0.01% + 3mA
Settings Resolution	Voltage	1mV
Settings Resolution	Current	1mA
Read Back Resolution	Voltage	1mV
Read Back Resolution	Current	1mA
Settings Accuracy (25℃ ± 5℃) (within 12 months)	Voltage	≤0.03% + 10mV
Settings Accuracy (25℃ ± 5℃) (within 12 months)	Current	≤0.1% + 8mA						≤0.1% + 5mA
Read Back Accuracy (25℃ ± 5℃)	Voltage	≤0.03% + 10mV
Read Back Accuracy (25℃ ± 5℃)	Current	≤0.1% + 8mA						≤0.1% + 5mA
Noise and Ripple (20Hz - 20MHz)	Voltage (Vp-p)	≤4mVp-p						≤3mVp-p
	Voltage (rms)	≤1mVrms						≤1mVrms
	Current (rms)	≤5mArms						≤4mArms
Output Temperature Coefficient (0℃ - 40℃)	Voltage	≤0.03% + 10mV
Output Temperature Coefficient (0℃ - 40℃)	Current	≤0.1% + 5mA
Read Back Temperature Coefficient	Voltage	≤0.03% + 10mV
Read Back Temperature Coefficient	Current	≤0.1% + 5mA
Parallel Settings Accuracy	Voltage	≤0.02% + 5mV
Parallel Settings Accuracy	Current	≤0.1% + 30mA
Programmable Output	Storage	100 groups
Programmable Output	Time Setting	second
Data Recording		10 K groups (of voltage, current data) recording capacity
Working Temperature		0 - 40℃
Communication Interface		USB Host&Divice, RS232, and LAN
